Lead-acid replacement
Model YL12200 · YL24200
Yilink LFP-ABS
12.8 V and 25.6 V lithium batteries — lead-acid replacement
The LFP-ABS series drops straight into an existing lead-acid housing: same formats, same M6 terminals, ABS case. It multiplies cycle life sevenfold and halves the weight.
- Voltages
- 12.8 / 25.6 V Voltages
- Capacities
- 50 – 200 Ah Capacities
- Cycle life
- 3,500+ Cycle life
- Design life
- 10 yr+ Design life
Seven references cover 12.8 V and 25.6 V, from 50 to 200 Ah — 0.64 to 5.12 kWh. More than 3,500 cycles at 25 °C, a design life beyond ten years and efficiency above 99%.
Highlights
- Drop-in lead-acid replacement — same formats and M6 terminals
- Seven references in 12.8 V and 25.6 V, from 50 to 200 Ah
- More than 3,500 cycles against a few hundred for lead-acid
- Design life beyond ten years
- Efficiency above 99% @ 0.2C
- Rugged ABS case, rack mountable
- Self-discharge under 2% per month at 35 °C
Installation
- Type
- Rack mount or existing battery housing
- Terminals
- M6
- Storage
- −10 to 45 °C, 60% ± 25% relative humidity
Technical specifications
| Chemistry | Lithium iron phosphate (LiFePO4) |
|---|---|
| Nominal voltages | 12.8 V and 25.6 V |
| Capacities | 50, 100, 150 and 200 Ah depending on reference |
| Energy | 0.64 to 5.12 kWh depending on reference |
| Charge voltage | 14.4 – 14.8 V (12 V) · 28.8 – 29.6 V (24 V) |
| Charge method | CC-CV — 0.2C to 14.4 V, then tapering to 0.02C |
| Cycle life | ≥ 3,500 cycles @ 25 °C (0.2C, 80% DoD) |
| Design life | ≥ 10 years |
| Monthly self-discharge | ≤ 2% @ 35 °C |
| Charge and discharge efficiency | ≥ 99% @ 0.2C |
| Internal resistance | ≤ 60 to 80 mΩ depending on reference |
| Charging temperature | 0 to 55 °C |
| Discharging temperature | −20 to 60 °C |
| Storage temperature | −10 to 45 °C |
| Case | ABS |
| Terminals | M6 |
| Dimensions | from 229 × 138 × 208 mm to 522 × 268 × 252 mm depending on reference |
Certifications and safety
- UL 9540A
- UL 1973
- UN 38.3
- RoHS
- IEC 62619
- CE-IEC 61000
- IEC 62040
- MSDS
Warranty and support
10-year manufacturer warranty. Technical support and after-sales service provided by Yilink Canada, with a reply within 24 hours and direct access to the factory engineers.
